Tiny - Core i5 6500T / 2.5 GHz - RAM 8 GB - SSD 256 GB - TCG Opal Encryption - HD Graphics 530 - Gigabit Ethernet - Win 10 Pro 64-bit - monitor: none - black
| Main Specifications | |
|---|---|
| Product Description | Lenovo ThinkCentre M710q - tiny - Core i5 6500T 2.5 GHz - 8 GB - SSD 256 GB |
| Type | Personal computer - tiny |
| Processor | Intel Core i5 (6th Gen) 6500T / 2.5 GHz (, up to 3.1 GHz, (Quad-Core) |
| Processor Main Features | Intel Turbo Boost Technology 2 |
| Cache Memory | 6 MB |
| Cache Per Processor | 6 MB |
| RAM | 8 GB (installed) / 32 GB (max) - DDR4 SDRAM - non-ECC |
| Storage Controller | SATA (SATA 6Gb/s) |
| Hard Drive | SSD 256 GB - PCI Express 3.0 x4 - M.2 2280 - TCG Opal Encryption |
| Optical Storage | No optical drive |
| Graphics Controller | Intel HD Graphics 530 |
| Networking | 1GbE |
| Power | AC 120/230 V (50/60 Hz) |
| OS Provided | Windows 10 Pro 64-bit Edition |
| Color | Black |
| Dimensions (WxDxH) | 7 in x 7.2 in x 1.4 in |
| Weight | 2.91 lbs |
| Environmental Standards | ENERGY STAR Qualified |
| General | |
| Type | Personal computer |
| Product Form Factor | Tiny |
| Built-in Devices | Speaker |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Color | Black |
| Expansion / Connectivity | |
| Slots | 2 (total) / 1 (free) x SO-DIMM 260-pin ¦ 1 (total) / 0 (free) x CPU ¦ 2 (total) / 1 (free) x M.2 Card |
| Interfaces | 6 x USB 3.1 Gen 1 (2 front, 4 rear) (one of them is Always On and fast-charging) ¦ 1 x microphone (1 in front) ¦ 1 x headphones/microphone (1 in front) ¦ 1 x LAN (Gigabit Ethernet) ¦ 2 x DisplayPort ¦ 1 x VGA |
| Miscellaneous | |
| Included Accessories | VESA mounting kit |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), chassis intrusion switch |
| Security Slot Type | Kensington security slot |
| Compliant Standards | RoHS, GREENGUARD, Energy-Related Products (ErP) Lot 3 |
| RAM | |
| Installed Size | 8 GB / 32 GB (max) |
| Technology | DDR4 SDRAM - non-ECC |
| Effective Memory Speed | 2133 MHz |
| Rated Memory Speed | 2400 MHz |
| Form Factor | SO-DIMM 260-pin |
| Slots | 2 (total) / 1 (empty) |
| Features | Dual channel memory architecture |
| Configuration Features | 1 x 8 GB |
| Networking | |
| Ethernet Controller | Intel I219-V |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features | Wake on LAN (WoL) |
| Power | |
| Device Type | Power adapter |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Provided | 65 Watt |
| Efficiency | 88% |
| Storage Controller | |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| Channel Qty | 1 |
| Cache Memory | |
| Installed Size | 6 MB |
| Cache Per Processor | 6 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel HD Graphics 530 |
| Video Interfaces | VGA, DisplayPort |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Operating System / Software | |
| OS Provided | Windows 10 Pro 64-bit Edition |
| Hard Drive | |
| Type | SSD - M.2 2280 |
| Capacity | 1 x 256 GB |
| Interface Type | PCI Express 3.0 x4 |
| Features | TCG Opal Encryption |
| Input Device | |
| Type | Mouse, keyboard |
| Dimensions & Weight | |
| Width | 7 in |
| Depth | 7.2 in |
| Height | 1.4 in |
| Weight | 2.91 lbs |
| Keyboard | |
| Interface | USB |
| Mouse | |
| Mouse Name | Lenovo Calliope Mouse |
| Interface | USB |
| Processor / Chipset | |
| CPU | Intel Core i5 (6th Gen) 6500T |
| Clock Speed | 2.5 GHz |
| Max Turbo Speed | 3.1 GHz |
| Number of Cores | Quad-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Processor Main Features | Intel Turbo Boost Technology 2 |
| Chipset Type | Intel B250 |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 6.1 |
