65" Diagonal Class (64.5" viewable) LED-backlit LCD display - digital signage - 4K UHD (2160p) 3840 x 2160 - Direct LED
| Main Specifications | |
|---|---|
| Product Description | ViewSonic Digital Display CDE6512 65" Class (64.5" viewable) LED-backlit LCD display - 4K - for digital signage |
| Product Type | LED-backlit LCD flat panel display |
| Diagonal Class | 65" |
| Diagonal Size | 64.5" |
| Commercial Use | Yes - digital signage |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Video Interface | HDMI |
| HDMI Ports Qty | 2 ports |
| Connectivity | Wi-Fi, LAN |
| PC Interface | VGA (HD-15), USB, serial RS-232 |
| LCD Backlight Technology | Direct LED |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Speaker System | 2 speakers |
| Storage Capacity | 16GB eMMC |
| USB | Yes |
| Included Accessories | Remote control, mounting screws, ViewBoard software |
| Voltage | (50/60 Hz) |
| Power Consumption Operational | 220 Watt |
| Power Consumption Stand by | 0.5 Watt |
| Dimensions (WxDxH) | 57.5 in x 3.2 in x 33.2 in |
| Weight | 44.75 lbs |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Power Consumption (Max) | 300 Watt |
| Power Consumption Operational | 220 Watt |
| Diagonal Class | 65" |
| Diagonal Size | 64.5" |
| Commercial Use | Yes - digital signage |
| Operating System | Android OS 11 |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| HDMI Ports Qty | 2 ports |
| PC Interface | VGA (HD-15), USB, serial RS-232 |
| Width | 57.5 in |
| Depth | 3.2 in |
| Height | 33.2 in |
| Weight | 44.75 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years ¦ Limited warranty - backlight - 3 years |
| Miscellaneous | |
| Included Accessories | Mounting screws, ViewBoard software |
| Cables Included | HDMI cable ¦ RS-232 cable |
| Compliant Standards | FCC, RoHS, cULus |
| Power | |
| Power Device | Power supply |
| Input Voltage | (50/60 Hz) |
| Power Consumption Stand by | 0.5 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 80% (non-condensing) |
| Display | |
| Color Support | 1070000000 colors |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 16:9 |
| LCD Backlight Technology | Direct LED |
| Coating | Anti-glare, 3H Hard, 2% haze |
| Image Contrast Ratio | 1200:1 |
| Dynamic Contrast Ratio | 5000:1 |
| Brightness | 290 cd/m² |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Response Time | 8 ms |
| Backlight Life | 30,000 hour(s) |
| Operation Hours / Days | 16 / 7 |
| Connections | |
| Connector Type | Audio input ¦ SPDIF output ¦ USB 2.0 ¦ USB ¦ 2 x HDMI input ¦ RS-232 input ¦ VGA input / output ¦ LAN ¦ Audio output |
| Remote Control | |
| Type | Remote control |
| Battery Included | Yes |
| Audio System | |
| Speaker System | 2 speakers |
| Output Power / Total | 20 Watt |
| Speakers | 2 x main channel speaker - 10 Watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 62.4 in |
| Depth (Shipping) | 7.1 in |
| Height (Shipping) | 37.3 in |
| Weight (Shipping) | 59.08 lbs |
| Network & Internet Multimedia | |
| Connectivity | Wi-Fi, LAN |
| Stands & Mounts | |
| Flat Panel Mount Interface | 300 x 200 mm |
| VESA Compatibility | Yes |
| Media Player | |
| USB Port | Yes |
| USB Ports Qty | 1 |
| Configuration | Quad-Core ( 1.5 GHz ) - 2 GB DDR4 - 16GB eMMC - Mali-G52 MP2 |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
