Label printer - direct thermal - - 203 dpi - up to 359.1 inch/min - USB 2.0, Bluetooth 5.0 LE, NFC, Wi-Fi(ac)
| Main Specifications | |
|---|---|
| Product Description | SATO PW4NX - label printer - B/W - direct thermal |
| Printer Type | Label printer - direct thermal - B/W |
| Weight | 3.17 lbs |
| Max Media Size | Roll (2.64 in) |
| Print Speed | Up to 359.1 inch/min |
| Max Resolution (B&W) | 203 dpi |
| Interface | USB 2.0, Bluetooth 5.0 LE, NFC, Wi-Fi(ac) |
| Language Simulation | SBPL, SIPL, SZPL |
| Barcodes | Aztec code, Bookland, Codabar, Code 128, Code 39, Code 93, Data Matrix, EAN/JAN, GS1 DataBar Expanded, GS1 DataBar Expanded Stacked, GS1 DataBar Limited, GS1 DataBar Omnidirectional, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1-128, Industrial 2 of 5, ITF, Matrix 2 of 5, MaxiCode, Micro QR code, MicroPDF417, NW-7, PDF417, QR code, UCC/EAN-128, UPC-A, UPC-E |
| Media Type | Continuous forms, linerless labels, receipt paper, die cut labels |
| Power | AC 100-240 V |
| Battery | Lithium ion |
| Manufacturer Warranty | 1-year warranty |
| Dimensions (WxDxH) | 7.1 in x 7.7 in x 2.7 in |
| General | |
| Printer Type | Label printer - direct thermal - monochrome |
| Expansion / Connectivity | |
| Connections | 1 x USB 2.0 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Compliant Standards | IEC 60950-1, EN 60950-1, EN55022, EN 55032, EN55024, EN 61000-3-2, EN 61000-3-3, EN 301 489-1, EN 301 489-3, EN 301 489-17, EN 300 330-2, EN 300 330-1, MET, cMETus, FCC-15 (Class A), FCC-15 (Class B), CCC, SRRC, iDA, SIRIM, NTC, SDPPI, RCM |
| Printer | |
| Print Speed | Up to 359.1 inch/min |
| Connectivity Technology | Wireless |
| Interface | USB 2.0, Bluetooth 5.0 LE, NFC, Wi-Fi(ac) |
| Max Resolution (B&W) | 203 dpi |
| Language Simulation | SBPL, SIPL, SZPL |
| Barcodes | Aztec code, Bookland, Codabar, Code 128, Code 39, Code 93, Data Matrix, EAN/JAN, GS1 DataBar Expanded, GS1 DataBar Expanded Stacked, GS1 DataBar Limited, GS1 DataBar Omnidirectional, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1-128, Industrial 2 of 5, ITF, Matrix 2 of 5, MaxiCode, Micro QR code, MicroPDF417, NW-7, PDF417, QR code, UCC/EAN-128, UPC-A, UPC-E |
| Media Handling | |
| Media Type | Continuous forms, linerless labels, receipt paper, die cut labels |
| Max Media Size | Roll (2.64 in) |
| Max Printing Width | 4.09 in |
| Max Printing Length | 3.3 ft |
| Media Thickness Range | 0.058 mm - 0.1905 mm |
| Roll Maximum Outer Diameter | 2.6 in |
| Power | |
| Power Device | Power adapter - external |
| Voltage Required | AC 100-240 V |
| Frequency Required | 50/60 Hz |
| Environmental Parameters | |
| Min Operating Temperature | 5 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 10 - 90% RH (non-condensing) |
| Battery | |
| Type | Lithium ion |
| Capacity | 2550 mAh |
| Dimensions & Weight | |
| Width | 7.1 in |
| Depth | 7.7 in |
| Height | 2.7 in |
| Weight | 3.17 lbs |
