SFF 1 x Core i7 8700 / up to 4.6 GHz - RAM 64 GB - SSD 1 TB - NVMe, TLC - DVD-Writer - UHD Graphics 630 - Gigabit Ethernet - monitor: none - keyboard: US
| Main Specifications | |
|---|---|
| Product Description | HP Engage Flex Pro Retail System - SFF Core i7 8700 3.2 GHz - 64 GB - SSD 1 TB - US |
| Type | Point of sale terminal - SFF |
| Localization | Language: English / region: United States |
| Processor | 1 x Intel Core i7 (8th Gen) 8700 / 3.2 GHz (up to 4.6 GHz, (6-core) |
| Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache |
| Cache Memory | 12 MB L3 cache |
| Cache Per Processor | 12 MB |
| RAM | 64 GB (installed) / 64 GB (max) - DDR4 SDRAM - non-ECC |
| Hard Drive | SSD 1 TB - PCI Express - M.2 - NVM Express (NVMe), triple-level cell (TLC) |
| Optical Storage | DVD-Writer |
| Graphics Controller | Intel UHD Graphics 630 Dynamic Video Memory Technology |
| Audio Output | Stereo |
| Networking | 1GbE |
| Keyboard | US |
| Dimensions (WxDxH) | 13.3 in x 15 in x 3.9 in |
| Weight | 14.2 lbs |
| Environmental Standards | ENERGY STAR Qualified EPEAT Silver |
| General | |
| Type | Point of sale terminal |
| Product Form Factor | SFF |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Localization | Language: English / region: United States |
| Expansion / Connectivity | |
| Bays | 2 internal 3.5" |
| Slots | 2 (total) / 2 (free) x PCIe x1 - full-height ¦ 1 (total) / 1 (free) x PCIe x16 - half-height (x16 mode) ¦ 1 (total) / 1 (free) x PCIe x16 - half-height (x4 mode) ¦ 2 M.2 Card |
| Interfaces | 2 x USB 2.0 ¦ 5 x USB 3.1 Gen 1 (2 front, 3 rear) (one of them is charging) ¦ 1 x PS/2 keyboard / mouse ¦ 1 x DisplayPort 2.0 ¦ 1 x audio line-in/microphone ¦ 1 x LAN (Gigabit Ethernet) |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| Compliant Standards | IEC 60601-1-2, RoHS, WEEE, IEEE 1680 |
| RAM | |
| Installed Size | 64 GB (installed) / 64 GB (max) |
| Technology | DDR4 SDRAM - non-ECC |
| Effective Memory Speed | 2666 MHz |
| Rated Memory Speed | 2666 MHz |
| Form Factor | DIMM 288-pin |
| Slots | 4 (total) / 0 (empty) |
| Configuration Features | 4 x 16 GB |
| Networking | |
| Ethernet Controller | Intel I219-LM |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | SNMP 2 |
| Features | Wake on LAN (WoL), ACPI support, PXE support |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 85% RH |
| Cache Memory | |
| Installed Size | L3 cache - 12 MB |
| Cache Per Processor | 12 MB |
| Optical Storage | |
| Type | DVD-Writer |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics 630 Dynamic Video Memory Technology |
| Video Interfaces | DisplayPort |
| HDCP Compatible | Yes |
| Audio Output | |
| Sound Output Mode | Stereo |
| Max Sampling Rate | 192 kHz |
| Compliant Standards | High Definition Audio |
| Hard Drive | |
| Type | SSD - M.2 |
| Capacity | 1 x 1 TB |
| Interface Type | PCI Express |
| Features | NVM Express (NVMe), triple-level cell (TLC) |
| Input Device | |
| Type | Mouse, keyboard |
| Dimensions & Weight | |
| Width | 13.3 in |
| Depth | 15 in |
| Height | 3.9 in |
| Weight | 14.2 lbs |
| Keyboard | |
| Keyboard Name | HP Business Slim Keyboard |
| Interface | USB |
| Localization & Layout | US |
| Mouse | |
| Interface | USB |
| Processor / Chipset | |
| CPU | Intel Core i7 (8th Gen) 8700 |
| Clock Speed | 3.2 GHz |
| Max Turbo Speed | 4.6 GHz |
| Number of Cores | 6-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache |
| Chipset Type | Intel Q370 |
| Sustainability Information | |
| EPEAT Compliant | EPEAT Silver |
| ENERGY STAR Certified | Yes |
