Switch - managed - 24 x 10/100/1000 (PoE++) + 2 x combo Gigabit SFP - rack-mountable - PoE++ (1080 W) - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | Lantronix SM24TBT2DPB - switch - 24 ports - managed - rack-mountable - TAA Compliant |
| Device Type | Switch - 24 ports - managed |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 (PoE++) + 2 x combo Gigabit SFP |
| Power Over Ethernet (PoE) | PoE++ |
| PoE Budget | 1080 W |
| Performance | Backplane switching capacity: 52 Gbps |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 9KB |
| Routing Protocol | IGMP, IGMPv2, IGMPv3 |
| Remote Management Protocol | SNMP 1, SNMP 2c, SNMP 3, Telnet, TFTP, HTTP |
| Features | CSMA/CD, IPv4 and IPv6 dual stack, DHCP relay, DHCP server, IP source guard, MAC based VLAN, Port Security, port-based VLAN, PVE, tagged VLAN, VLAN management, DMS, APR, PoE scheduling, Always on PoE, topology view, traffic monitoring, CLI management, web-based management, IGMP snooping, IGMP proxy, GVRP, IGMP querier, Q-in-Q tunneling, SP, Voice VLAN, WRR |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1ad, IEEE 802.1ab (LLDP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3az |
| Power | AC 100-120/200-277 / DC 192-254/306-334 V (50/60 Hz) |
| Power Redundancy | Optional |
| Dimensions (WxDxH) | 17.4 in x 11.8 in x 1.7 in |
| Weight | 11.29 lbs |
| Localization | Japan |
| TAA Compliant | Yes |
| Manufacturer Warranty | 5-year warranty |
| General | |
| Device Type | Switch - 24 ports - managed |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 (PoE++) + 2 x combo Gigabit SFP |
| Power Over Ethernet (PoE) | PoE++ |
| PoE Budget | 1080 W |
| Performance | Backplane switching capacity: 52 Gbps |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 9KB |
| Routing Protocol | IGMP, IGMPv2, IGMPv3 |
| Remote Management Protocol | SNMP 1, SNMP 2c, SNMP 3, Telnet, TFTP, HTTP |
| Encryption Algorithm | SSL |
| Authentication Method | RADIUS, TACACS+, Secure Shell (SSH), Secure Shell v.2 (SSH2) |
| Features | CSMA/CD, IPv4 and IPv6 dual stack, DHCP relay, DHCP server, IP source guard, MAC based VLAN, Port Security, port-based VLAN, PVE, tagged VLAN, VLAN management, DMS, APR, PoE scheduling, Always on PoE, topology view, traffic monitoring, CLI management, web-based management, IGMP snooping, IGMP proxy, GVRP, IGMP querier, Q-in-Q tunneling, SP, Voice VLAN, WRR |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1ad, IEEE 802.1ab (LLDP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3az |
| Status Indicators | System, link/activity/speed, PoE, port status |
| Expansion / Connectivity | |
| Interfaces | 24 x 1000Base-T RJ-45 90 W ¦ 2 x 1000Base-X RJ-45/SFP ¦ 1 x console RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Included Accessories | 2 x power cords |
| Cables Included | 2 x Saf-D adapter cable |
| Rack Mounting Kit | Included |
| Compliant Standards | FCC Class A certified, UL 62368-1, NDAA |
| TAA Compliant | Yes |
| Localization | Japan |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 1 |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Power Provided | 1200 Watt - DC 54.5 V - 22.02 A |
| Voltage Required | AC 100-120/200-277 / DC 192-254/306-334 V (50/60 Hz) |
| Features | High Voltage DC (HVDC) |
| Software / System Requirements | |
| Software Included | Percepxion IoT Edge Solutions Platform |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 17.4 in |
| Depth | 11.8 in |
| Height | 1.7 in |
| Weight | 11.29 lbs |
