Standalone DVR - 16 channels - networked - rack-mountable
| Main Specifications | |
|---|---|
| Product Description | Speco H16HRLN - standalone DVR - 16 channels |
| Device Type | Standalone DVR - 16 channels - networked - rack-mountable |
| IP Cameras Supported | 8 |
| Frame Rate | 30 fps |
| Compression Format | H.265 |
| Image Resolution | 1920x1080, 1024x768, 1280x1024, 3840x2160 |
| Hard Drive(s) Supported | Quantity: 2 - total capacity: 32 TB |
| Dimensions (WxDxH) | 15 in x 10.6 in x 1.8 in |
| Manufacturer Warranty | 5 years |
| General | |
| Device Type | Standalone DVR - rack-mountable |
| Video Channels | 16 |
| IP Cameras Supported | 8 |
| Audio Channels | 8 |
| Image Resolution | 1920x1080, 1024x768, 1280x1024, 3840x2160 |
| Compression Format | H.265 |
| Package Content | Rack ears |
| OS Provided | Linux |
| Warranty | 5 years |
| Networking | |
| DDNS Support | Yes |
| Network Interfaces | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Supported Protocols | DDNS, DHCP, DNS, HTTP, NTP, SMTP, TCP/IP, RTSP, HTTPS, UPnP, PPPoE, P2P |
| Features | 720p resolution support, 1080p resolution support, 960p resolution support |
| Power | |
| Power Consumption | 15 Watt |
| Power Consumption Details | Without HDD |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 122 °F |
| Hard Drive | |
| Quantity Supported | 2 |
| Interface | Serial ATA |
| Supported Max Total Capacity | 32 TB |
| Connections | |
| Video Input Ports | BNC x 8 |
| Video Output Ports | HDMI x 1, BNC x 1, VGA x 1 |
| Audio Input Ports | RCA x 8 |
| Audio Output Ports | RCA x 1 |
| Alarm Ports | Alarm input x 8, alarm output x 2 |
| Network Port | 10/100/1000Base-T |
| Other Ports | USB 2.0 x 2, eSATA x 1 |
| Dimensions & Weight | |
| Width | 15 in |
| Depth | 10.6 in |
| Height | 1.8 in |
| Security DVR | |
| Frame Rate (Record) | 30 fps |
| Playback Search | Event, time, smart search, bookmark, snapshot, museum |
| Record Events | Alarm, motion detection, manual, line crossing detection, object detection |
| Networked | Yes |
| Features | 2-way audio communication |
