Rack-mountable 1U - no CPU up to - RAM 0 GB - no HDD - no graphics - Gigabit Ethernet - no OS - monitor: none - CTO
| Main Specifications | |
|---|---|
| Product Description | HP Workstation Z4 G5 - rack-mountable no CPU - 0 GB - no HDD |
| Type | Workstation - rack-mountable |
| Height (Rack Units) | 1U |
| Processor | No CPU |
| Processor Socket | LGA4677 Socket-E |
| RAM | 0 GB (installed) / 256 GB (max) - DDR5 SDRAM |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Graphics Controller | No graphics |
| Networking | 1GbE |
| Power | (50/60 Hz) |
| Power Redundancy | Yes |
| OS Provided | No operating system |
| Dimensions (WxDxH) | 17.2 in x 25.7 in x 1.7 in |
| Weight | 20.94 lbs |
| Pricing Type | CTO |
| General | |
| Type | Workstation |
| Product Form Factor | Rack-mountable - 1U |
| Built-in Devices | Speaker |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Expansion / Connectivity | |
| Bays | 2 (total) / 2 (free) x external 2.5" / 2xM.2 shared ¦ 2 (total) / 2 (free) x internal 2.5" / 2xM.2 shared / 1x3.5" |
| Slots | 1 (total) / 1 (free) x PCIe 5.0 x16 (x8 mode) ¦ 1 (total) / 1 (free) x PCIe 5.0 x16 ¦ 1 (total) / 1 (free) x PCIe 5.0 x8 (x8 mode) ¦ 2 (total) / 2 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode (for internal storage)) |
| Interfaces | 4 x USB 3.2 Gen 1 (4 in front) (one of them is charging) ¦ 2 x USB 3.2 Gen 1 (2 rear) ¦ 1 x headphones/microphone (1 in front) ¦ 1 x LAN (Gigabit Ethernet) (1 rear) |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop, chassis intrusion sensor |
| Security Slot Type | Kensington security slot |
| Compliant Standards | RoHS, ERP, CECP, CEL, WEEE 2002/96/EC, Common Criteria EAL4+, FIPS 140-2, JEDEC JESD 300-5, IT ECO Declaration, DASH 1.2, low halogen |
| Pricing Type | CTO |
| RAM | |
| Installed Size | 0 GB (installed) / 256 GB (max) |
| Technology | DDR5 SDRAM |
| Form Factor | DIMM 288-pin |
| Slots | 4 (total) / 4 (empty) |
| Networking | |
| Ethernet Controller | Intel I219-LM |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Features | Wake on LAN (WoL), auto-uplink (auto MDI/MDI-X), PXE 2.1 support |
| Power | |
| Device Type | Power supply |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1, N+1 |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Voltage Required | AC 90-269 V (50/60 Hz) |
| Power Provided | 675 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 8 - 85% RH (non-condensing) |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | No graphics |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Operating System / Software | |
| OS Provided | No operating system |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 17.2 in |
| Depth | 25.7 in |
| Height | 1.7 in |
| Weight | 20.94 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 23.2 in |
| Shipping Depth | 35.4 in |
| Shipping Height | 8.7 in |
| Processor / Chipset | |
| CPU | No CPU |
| Max CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| CPU Socket | LGA4677 Socket-E |
| Chipset Type | Intel W790 |
