SSD - encrypted - 7.68 TB - internal - E1.S 9.5mm - PCIe 4.0 x4 (NVMe) - 256-bit AES-XTS - TCG Opal Encryption 2.0
| Main Specifications | |
|---|---|
| Product Description | Samsung PM9A3 MZTL27T6HBLA - SSD - 7.68 TB - PCIe 4.0 x4 (NVMe) |
| Type | Solid state drive - internal |
| Capacity | 7.68 TB |
| Hardware Encryption | Yes |
| Encryption Algorithm | 256-bit AES-XTS |
| NAND Flash Memory Type | Multi-level cell (MLC) |
| Form Factor | E1.S 9.5mm |
| Interface | PCIe 4.0 x4 (NVMe) |
| Features | Static wear leveling, End-to-end data protection, V-NAND Technology, power loss data protection, Dynamic Wear Leveling, Samsung Elpis Controller, S.M.A.R.T. |
| Dimensions (WxDxH) | 1.3 in x 4.7 in x 0.4 in |
| Weight | 2.82 oz |
| General | |
| Device Type | Solid state drive - internal |
| Capacity | 7.68 TB |
| Hardware Encryption | Yes |
| Encryption Algorithm | 256-bit AES-XTS |
| NAND Flash Memory Type | Multi-level cell (MLC) |
| Form Factor | E1.S 9.5mm |
| Interface | PCIe 4.0 x4 (NVMe) |
| Bytes per Sector | 512 |
| Features | Static wear leveling, End-to-end data protection, V-NAND Technology, power loss data protection, Dynamic Wear Leveling, Samsung Elpis Controller, S.M.A.R.T. |
| Width | 1.3 in |
| Depth | 4.7 in |
| Height | 0.4 in |
| Weight | 2.82 oz |
| Miscellaneous | |
| Compliant Standards | TUV, VCCI, BSMI, cUL, CB, IC, FCC, RoHS, Halogen-free, KC, RCM |
| Power | |
| Power Consumption | 11 Watt (read) ¦ 13.5 Watt (write) ¦ 3.5 Watt (idle) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 158 °F |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 185 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Shock Tolerance (non-operating) | 1500 g |
| Vibration Tolerance (non-operating) | 20 g @ 20-2000 Hz |
| Performance | |
| Drive Writes Per Day (DWPD) | 1 |
| SSD Endurance | 14016 TB |
| Internal Data Rate | 6800 MBps (read) / 4000 MBps (write) |
| 4KB Random Read | 1000000 IOPS |
| 4KB Random Write | 190000 IOPS |
| Reliability | |
| MTBF | 2,000,000 hours |
| Non-Recoverable Errors | 1 per 10^17 |
| Expansion & Connectivity | |
| Interfaces | PCI Express 4.0 x4 (NVMe) |
| Compatible Bay | E1.S 9.5mm |
