For Microsoft Teams Rooms - conference camera - PTZ - bar - color - 12 MP - 3840 x 2160 - 4K UHD (3840 x 2160) - USB 3.0 - H.264, MJPEG, NV12, YUY2
| Main Specifications | |
|---|---|
| Product Description | ViewSonic UMB202 - for Microsoft Teams Rooms - conference camera - bar |
| Device Type | Conference camera - pan / tilt / zoom - bar |
| Audio | Built-in six beam-forming microphone array, built-in speaker |
| Dimensions (WxDxH) | 18.2 in x 3.7 in x 3 in |
| Connectivity Technology | Wired |
| Camera | Color |
| Max Resolution | 3840 x 2160 |
| Frame Rate (max) | 30 frames per second |
| Video Modes | 4K UHD (3840 x 2160) |
| Optical Sensor Type | CMOS - 1/2.3" - 12 MP |
| Interfaces | USB 3.0 |
| Cables Included | 1 - USB-C cable - 6 ft ¦ 1 - USB-C to USB-A adapter |
| Features | ePTZ, digital noise reduction, 8m microphone pickup range, 117.8° diagonal field of view (DFOV), 109° horizontal field of view (HFOV), 74.4° vertical field of view (VFOV), white balance, exposure control, DOA voice tracking technology, microphone mute control, USB video class (UVC 1.1), auto-framing, voice tracking, 11W front-facing speaker, PoE+ support, security slot (Kensington security lock compatible) |
| General | |
| Device Type | Conference camera |
| Audio Support | Built-in six beam-forming microphone array, built-in speaker |
| Form Factor | Bar |
| Connectivity Technology | Wired |
| Width | 18.2 in |
| Depth | 3.7 in |
| Height | 3 in |
| Expansion / Connectivity | |
| Ports | USB 3.0 - 24-pin USB-C ¦ Audio line out ¦ LAN/power - RJ-45 |
| Miscellaneous | |
| Included Accessories | Remote control, wall mount components, screws, lens cover, power adapter |
| Cables Included | 1 x USB-C cable - 6 ft ¦ 1 x USB-C to USB-A adapter |
| Compliant Standards | IEEE 802.3at |
| Power | |
| Power Device | Power adapter |
| Software / System Requirements | |
| OS Required | Windows 11, Windows 10, Windows 8.1, Microsoft Windows 7, Apple macOS 10.10 or later, Android |
| Camera | |
| Type | Color - pan / tilt / zoom |
| Digital Video Format | H.264, MJPEG, NV12, YUY2 |
| Max Digital Video Resolution | 3840 x 2160 |
| Video Modes | 4K UHD (3840 x 2160) |
| Digital Zoom | 5 |
| Digital Video Capture Resolution | 3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 720, 1024 x 576, 960 x 540, 800 x 600, 640 x 480, 640 x 360, 480 x 270, 352 x 288, 320 x 240 |
| Frame Rate (max) | 30 frames per second |
| Features | ePTZ, digital noise reduction, 8m microphone pickup range, 117.8° diagonal field of view (DFOV), 109° horizontal field of view (HFOV), 74.4° vertical field of view (VFOV), white balance, exposure control, DOA voice tracking technology, microphone mute control, USB video class (UVC 1.1), auto-framing, voice tracking, 11W front-facing speaker, PoE+ support, security slot (Kensington security lock compatible) |
| Image Sensor | |
| Type | 12 MP CMOS 1/2.3" |
| Interfaces | |
| Computer Interface | USB 3.0 |
