Wireless access point - BE11000 - 1GbE, Wi-Fi 7, 2.5GbE - Wi-Fi 7 - 2.4 GHz, 5 GHz, 6 GHz - cloud-managed
| Main Specifications | |
|---|---|
| Product Description | Zyxel NebulaFlex Pro WBE530 - wireless access point - BE11000 - Wi-Fi 7 - cloud-managed |
| Device Type | Wireless access point |
| Form Factor | External |
| Data Link Protocol | Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11be (Wi-Fi 7), 2.5 Gigabit Ethernet |
| Frequency Band | 2.4 GHz, 5 GHz, 6 GHz |
| Performance | Maximum data rate (6 GHz): 5764 Mbps ¦ Maximum data rate (5 GHz): 4324 Mbps ¦ Maximum data rate (2.4 GHz): 688 Mbps ¦ Channel width: 20 / 40 / 80 / 160 / 240 / 320 MHz |
| Included Accessories | Mounting plate, mounting screws |
| Power Over Ethernet (PoE) Supported | PoE+ |
| Dimensions (WxDxH) | 9.8 in x 6.3 in x 1.9 in |
| Weight | 28.5 oz |
| General | |
| Device Type | Wireless access point |
| Width | 9.8 in |
| Depth | 6.3 in |
| Height | 1.9 in |
| Weight | 28.5 oz |
| Expansion / Connectivity | |
| Interfaces | 1 x 2.5Gb Ethernet (uplink, PoE+) - RJ-45 ¦ 1 x 1/2.5Gb Ethernet - RJ-45 |
| Miscellaneous | |
| Included Accessories | Mounting plate, mounting screws |
| MTBF | 698,312 hour(s) |
| Compliant Standards | FCC Part 15 C, FCC Part 15 E, BSMI CNS 15598-1, BSMI CNS 15936, EN 301 489-1, EN 301 489-17, EN 301 893, EN 303 687, EN 50385, EN 50665, EN 55032, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 62368-1, EN IEC 62311, EN60601-1-2, ETSI EN 300 328, FCC Part 15 B, FCC Part 2.1091, IEC 62368-1, LP0002 |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11be (Wi-Fi 7), 2.5 Gigabit Ethernet |
| Network / Transport Protocol | IPv6 |
| Remote Management Protocol | SNMP |
| Cloud-Managed | Yes |
| Frequency Band | 2.4 GHz, 5 GHz, 6 GHz |
| Performance | Maximum data rate (6 GHz): 5764 Mbps ¦ Maximum data rate (5 GHz): 4324 Mbps ¦ Maximum data rate (2.4 GHz): 688 Mbps ¦ Channel width: 20 / 40 / 80 / 160 / 240 / 320 MHz |
| Wi-Fi Rating | BE11000 |
| Features | MU-MIMO technology, 2x2 MU-MIMO technology, 2x2:2 streams, band steering, WDS/Mesh, NebulaFlex Pro support, Fast Roaming, Pre-Authentication, PMK Caching, Dynamic Channel Selection (DCS), Advanced Cellular Coexistence (ACC), load balancing, L2-isolation, MAC address filtering, rogue AP detection, VLAN support, Wi-Fi Multimedia (WMM) support, Unscheduled Automatic Power Save Delivery (U-APSD), standalone use, ZON Utility |
| Encryption Algorithm | WPA, WPA2, WPA3, WEP |
| Authentication Method | RADIUS |
| Compliant Standards | IEEE 802.11k, IEEE 802.11r, IEEE 802.11v, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ax, IEEE 802.11ac, IEEE 802.11be, Wi-Fi CERTIFIED 7, IEEE 802.1x, IEEE 802.3bt, IEEE 802.3at |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE+ |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 10 - 95% (non-condensing) |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 11 in |
| Shipping Depth | 7.1 in |
| Shipping Height | 2.6 in |
| Shipping Weight | 2.28 lbs |
| Antenna | |
| Antenna | Internal |
