Storage controller (RAID) - M.2 - M.2 NVMe Card - RAID 0, 1, 10 - PCIe 4.0 x16
| Main Specifications | |
|---|---|
| Product Description | HighPoint SSD7000 Gen4 Series SSD7749M2 - storage controller (RAID) - M.2 NVMe Card - PCIe 4.0 x16 |
| Device Type | Storage controller (RAID) - plug-in card |
| Bus Type | PCIe 4.0 x16 |
| Hard Drive Form Factor Compatibility | M.2 |
| Interface | M.2 NVMe Card |
| Data Transfer Rate | 28 GBps |
| Supported Devices | Disk array (RAID) |
| RAID Level | RAID 0, RAID 1, RAID 10 |
| Product Material | Aluminum |
| System Requirements | Microsoft Windows 10 / 11, Microsoft Windows Server 2022, Microsoft Windows Server 2019, Microsoft Windows Server 2016, Microsoft Windows Hyper-V Server, Red Hat Enterprise Linux, Debian, Ubuntu, Fedora, Proxmox, Rocky Linux, Linux Kernel 3.10 or later |
| Dimensions (WxDxH) | 11.2 in x 1.5 in x 4.3 in |
| Weight | 3.24 lbs |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Storage controller (RAID) - plug-in card |
| Hard Drive Form Factor Compatibility | M.2 |
| Host Bus | PCIe 4.0 x16 |
| Product Material | Aluminum |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Features | Audible alarm, LED indicator, full-height, full-length, dual-width, built-in low noise cooling fan, thermal padding, fan control, tool-less mounting, Storage Health Inspector, NVMe SMART status, configurable RAID auto-rebuilding priority, Cross-Sync technology, Bootable RAID Array support, multiple RAID partitions supported, online array roaming, Quick RAID Initialization, global hot spare disk support |
| MTBF | 920,585 hours |
| Compliant Standards | FCC, REACH, RoHS, WEEE |
| Power | |
| Power Consumption Operational | 17.28 Watt |
| Software / System Requirements | |
| Software Included | Command Line Interface (CLI), WebGUI (Browser-Based management tool) |
| OS Required | Microsoft Windows 10 / 11, Microsoft Windows Server 2022, Microsoft Windows Server 2019, Microsoft Windows Server 2016, Microsoft Windows Hyper-V Server, Red Hat Enterprise Linux, Debian, Ubuntu, Fedora, Proxmox, Rocky Linux, Linux Kernel 3.10 or later |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 131 °F |
| Storage Controller | |
| Interface | M.2 NVMe Card |
| Data Transfer Rate | 28 GBps |
| Supported Devices | Disk array (RAID) |
| RAID Level | RAID 0, RAID 1, RAID 10 |
| Dimensions & Weight | |
| Width | 11.2 in |
| Depth | 1.5 in |
| Height | 4.3 in |
| Weight | 3.24 lbs |
